Homelab
Overview
The lag for smart bulbs to turn on always takes too long. Because most widely available IoT devices take a trip from your house to a data center and then back to execute a command like “set the lights to yellow.” The solution is to do it locally! A simple small server that acts as a central hub running software
like Home Assistant can be installed on a Raspberry Pi. So, what a normal person would do, I bought a brand-new second-hand small form factor workstation. An overpowered computer for a small task. But this way could allow us to host other services, like file sharing, ad blocking, media backups, and playback, to name a few,
with little help from virtualization. This technology lets you create virtual simulated servers, networks, or another physical machine, essentially cutting up the hardware resources and allocating them to multiple little virtualized computers.
This can be done on a normal computer using Windows. However, I decided to go for a type one hypervisor for the main operating system. This reduces the “noise“ for allocating underlying resources. Additionally, it's safe and ideal for experimenting with new technologies, and you can spin up a VM or lightweight containers (LXC) in seconds.
For me, having a playground to tinker makes me less anxious if I mess things up, I won't have to worry about breaking my main gear.
Goals
- Host my own services (file sharing and media streaming, home automation, private cloud)
- Testbed for new technologies (isolation)
- Lower cost of backing up and storing data
- Own my data and Achieve data privacy
-
- Access it from anywhere
Hardware & software
Implementation
I found an HP Z240 workstation, which will be enough to run all of the services I want and some more. I started by gutting the computer and then putting it in a roomy-er tower to make space for the new HDD, which we’ll need to store our data. After installing two additional 8GB RAM sticks (check what the max RAM is for you) for a total of 32GB of RAM,
16GB was more than enough, but more is better. My 2.5GB network card didn't arrive at this time. So I proceeded to install the OS of my choosing from a USB to the SSD. This is what is amazing about having a server you can add this later. After going through the setup wizard for Proxmox and setting the password, region, and IP address (which must be static),
you have to remember them for the next step.
The first thing I installed was Pi-Hole in an LXC, an open-source DNS that lets you monitor local internet traffic and, most importantly, block ads on a network gateway level. So you can enjoy an ad-free experience on all the devices. Later, I wanted to fix what started it all. A local IoT automation solution that will eliminate our need to rely on companies' data centers and unify all controls on a single app. When normal consumers have smart home devices, they are highly likely to have more than one app. Each company will try to host its own service, such as Philips TP-link or Tuya. Home Assistant is a home automation application that has an “app store” to download all of your IoT device's apps and control them from one dashboard.
Next, I started tackling NAS (Network-attached storage) for file storage and sharing.
There are many options like TrueNAS, Cockpit, or UNRAID. I installed my 3 2TB HDD and Finally decided to go for TrueNAS because it checked all the boxes for me, like ZFS storage, and has an active community. I spun up a VM, installed it, and then created a file share. Now that we have a machine that can be used to create VMs and containers in isolation and saved up in the long term on storage from the cloud and physically own our data and media, we have knocked down most of our goals. But to securely reach the server from outside the home network, you’d have to expose it to the internet. A simple way is to use a VPN. While searching for a solution, I came across Tailscale. Simply it >>>>>>>>>>. So I spun up an Ubuntu LXC and followed their documentation to advertise the network and made it an exit node. This lets you tunnel any internet traffic through the server from anywhere without exposing any ports.
Future Upgrades
next cloud for cloud storage
Setup media storagw and streaming.
